Cheetah Chassis 33’ BRIDGEMASTER EXTENDABLE 3-AXLE CHASSIS
| Manufacturer: Cheetah Chassis |
Request More Info
Detailed Specifications
BRIDGEMASTER EXTENDABLE 3-AXLE CHASSIS
Approximately 11,100 lb.
65,000 lb.
All structural steel is ASTM-A572, Grade 50, or ASTM-A607, Grade 50 or better. All structural fasteners are Grade 5 or better and are zinc coated
Fabricated I-beam
Fabricated high-tensile steel
Fabricated steel
0.25"-thick pick up plate
48 inches
6" × 8" tube
6" × 8" tube
33 feet
43 feet
96 inches
Steel outboard mounted
Two-leaf spring ride
Description
The 33′ Bridgemaster chassis can carry one 20 ft. ISO container rated for 24 metric tons (using a 16,200 lb tractor). Its sliding frame allows this chassis to extend to a maximum 41′ length, allowing it to carry heavy-loaded 20′ ISO containers that would be illegal to transport over the road on a standard 23.5′ Slider chassis.
This extendable container chassis is assembled in the USA and built to last, featuring state-of-the-art fabrication, welding, and paint systems.
